AUTEL MaxiTPMS TS601 Car Diagnostic tool OBD2 Scanner


Tyre Pressure Monitoring System

469.00 including 23% VAT Rate

Subtotal:

Add-ons total:

Total:

AUTEL MaxiTPMS TS601 Car Diagnostic tool OBD2 Scanner

https://www.youtube.com/watch?v=3vAzPJUdao8

​AUTEL MaxiTPMS TS601 TPMS diagnostic & service tool
■ Introduction

The MaxiTPMS TS601 is the most powerful TPMS diagnostic & service tool in the world capable of fully diagnosing TPMS problems as well as activating TPMS sensors and reprogramming the vehicle’s ECU. This professional tool is the best solution for tire shops and automotive workshops to perform TPMS service!



■ Features

1. Activates all known OEM/Universal TPMS sensors using 125KHz continuous or modulated wave signals;
2. Reads sensor data including sensor ID, tire pressure, temperature, battery condition, OEM part number, OEM sensor maker and OEM frequency;
3. Allows you to directly read feedback from all 4 sensors, clearly view the status of all TPMS sensors, and compare sensor and ECU data to instantly pinpoint system faults;
4. Offers on-tool relearn procedure for every TPMS-equipped American, Asian and European vehicle. No need for relearning charts or internet lookups;
5. Programs AUTEL MX-Sensor with multiple options available including Auto Create, Manual Create, or Clone Sensor IDs with no sensor re-learn required for sensor positioning;
6. Offers OBD II Relearn to write IDs to vehicles directly without further procedures;
7. Offers visual/audio responses to make the operations much easier to complete;
8. Checks Remote Keyless Entry-Key FOB for transmissions;
9. Incredibly easy to use with intuitive navigation and step-by-step on-screen instructions.

■ Professional TPMS Diagnosis and Programming

The easy-to-use TPMS tool Autel TS601 provides users with unparalleled experience of efficiency and accuracy for complete TPMS diagnosis. Instead of simply checking the sensor data, sensor ID, tire pressure/temperature, battery condition, sensor position and diagnosing the TPMS to read/write sensor ID, read/clear TPMS codes (turn off TPMS warning light), retrieve TPMS ECU information, and perform actuation test, this TPMS tool allows user programming the sensor data to MX-sensor and replacing faulty sensor that is with low battery life or is not functioning.
Fast Access to Accurate OBDII Diagnosis
Autel TS601 is the first one to integrate the TPMS tool with OBDII code reader.  Except  professional diagnosis to the TPMS, you can also perform  the exceptional  diagnosis to vehicle engine running conditions and the operating status of the exhaust after-treatment, which is called OBDII diagnosis.
With OBDII diagnostic functions, you can quickly check the vehicle self-inspection condition, accurately locate the fault that caused the Check Engine Light, and easily turn off the check engine light after the maintenance and repair.
Easy and Fast MX-Sensor Programming
The TPMS sensor programming can and will only work with the Autel MX-sensor. There are 4 options available for you to complete MX-sensor programming, and they each have their own advantages and characteristics:
Auto Create applying random ID for the tested vehicle
Manual Create manually input the random ID or the original sensor ID
Copy by OBD read sensor ID with Relearn function, and write it to MX-sensor
Copy by Activation automatically write in the retrieved original sensor data to MX-sensor in the case of  original  sensor is triggered

■ Functions

1.Activates ALL magnetic, frequency and tire deflation triggered sensors using 125KHz continuous
2.modulated wave signals
3.Receives both 315MHz and 433MHz signals
4  .Reads   / writes sensor ID from vehicle ECU
5 .Reads   / clears codes of TPMS system and resets malfunction indicator light
6 .Reads   activated sensor data including sensor ID, tire pressure, temperature, battery condition, OE part number, relearn information
7.Reads, records   and   playbacks TPMS live data, including tire pressure, signal status, temperature, battery status, etc.
8.Retrieves TPMS ECU information
9.Performs actuation tests and special functions
10.Programs vehicle ECU to learn sensor IDs and positions
11.Capable of programming single tires for Chrysler, Renault, and Citroen
12.Checks Remote Keyless Entry (Key FOB) for transmissions
13.Graphs vehicle with 4 or 5 wheels to simplify the diagnostic process
14  .Pre-selection  process offers faster activation and diagnostics
15.Provides visual and audible responses to confirm sensors are working properly
16.On-screen code definitions
17.Incredibly easy to use with intuitive navigation and step-by-step on-screen instructions
18.Proper LF signal to prevent being fooled by other RF signals
19.Built-in rechargeable Li-polymer battery
20.Automatic power-off to preserve battery life
21.Multilingual support: English, French, and Spanish and more languages around the world.
22.Lifetime free update on the internet via USB port
23. Ergonomic design features strong housing and protective rubber boot

■ Update

Lifetime Free Update Online.

■ Supported Car Brands

For ABARTH, for Acuba, for Alfa Romeo, For Alpina, for Aston Martin, for Audi,for Bentley,  for BMW, for Bugatti, for Buick, for BYD, for Cadillac, for ChangAn, for Chery, for Chevrolet,  for Chrysler, for Citroen, for Dacia, for Daewoo, for Dodge, for Ferrari, for Fiat, for Ford,  for Foton, for Geely, for GMC, for GreatWall, for Haval, for Holden, for Honda, for HSV, for Hummer,  for Hyundai, for Infiniti, for ISUZU, for JAC, for Jaguar, for Jeep, for Junpai, for KIA, for Lada,  for Lamborghini, for Lancia, for LandRover, for Lexus, for Lifan, for Lincoln, for Lotus, for Mahindra,  for Maserati, for Maybach, for Mazda, for McLaren, for Mercedes Benz, for Mercury, for MG, for Mini,  for Mitsubishi, for Nissan, for Oldsmobile, for Opel, for Peugeot, for Plymouth, for Pontiac, for Porsche,  for Renault, for Rolls-Royce, for SAAB, for Samsung, for Saturn, for Scion, for Skoda, for Smart, for SsangYong,  for Subaru, for Suzuki, for Tesla, for Toyota, for Venucia, for Volvo, for VPG, for VW.
